Amplicon Impact-P 100A series

Ultra-small form factor IoT edge ready embedded computers. Intel ATOM x5-E3940 processor, -40°C to 85°C

  • Atom™ processor E3900 product family
  • Cellular or Wi-Fi connectivity
  • Windows 10, Windows 10 IoT and Linux support
  • Ultra-compact size for easy installation
  • -40°C to 85°C operating temperature range

The Amplicon Impact-P 101A is an ultra small form factor IoT edge ready embedded computer, utilising the superb Intel Intel Atom® x5-E3940 Apollo Lake processor.

Due to its carbon fibre composite and aluminium construction, these units are tough and lightweight, allowing them to be mounted nearly anywhere.

With options for wide temperature operations as well as cellular and WI-FI capability, the Impact-P 100A series is suitable for a wide range of applications, such as machine monitoring and remote I/O monitoring and control.

The new Impact-P 100A features integrated Cellular and Wi-Fi connectivity, free IoT management software, high performance Intel Atom processor and an extremely wide operating temperature range.

CPU
ATOM®
Memory
4 GB
OS Support
Linux
Windows 10
Windows 10 IoT
Expansion
mPCIe
M.2
Storage
32GB eMMC
Memory Type
DDR4
CPU Generation
Apollo Lake
CPU Cores (Physical)
4
Max Memory
4 GB
Max Operating Temperature
85 °C
Mounting
DIN Rail
Brand
Impact-P
Impact-P_101A
Datasheet 6.21 MB
Impact-E_D_T_P_roadmap
Roadmaps 3.36 MB

Models available (1)
